MT6825
MediaTek 5G
Satellite (NTN)
MediaTek 6G
Satellite (NTN)
3GPP Release-17 IoT-NTN Satellite Communication Solution
MT6825 is a highly integrated, extremely power-efficient, and robust IoT-NTN connectivity solution that can provide global satellite coverage for mobile applications such as messaging, tracking, and emergency services, as well as large-scale satellite IoT applications such as remote monitoring of utilities, infrastructure management, maritime, connected agriculture, fleet management, telematics, and more.
MediaTek has been a significant driver in the formulation and implementation of the 3GPP Non-Terrestrial-Network (NTN) standard, which was created to overcome coverage issues and difficult use-cases that ground-based infrastructure alone cannot address.
Key Features
The highly integrated MT6825 combines an Arm Cortex-M4F, PSRAM, Flash memory, cellular/satellite transceiver (RF), and a power management unit (PMU) in an extremely compact package, reducing time-to-market, while multiple interfaces allow easy platform integration. MediaTek's sophisticated power-efficiency technologies ensure the chip is particularly suitable for battery-powered devices such as smartphones or other mobile UE.
MT6825 supports 3GPP Release-17 (IoT-NTN) at L-band and S-band frequencies for satellite communications.
MT6825 has been awarded “Disruptive Device Innovation Award” at the Asia Mobile Awards, held during MWC Shanghai 2023.
Specifications
Processor
CPU
Arm Cortex-M4 with FPU
CPU Core Count
Single (1)
CPU Frequency
156MHz
Memory
32KB + 32Mbit PSRAM
Flash
32Mbit
Connectivity
NTN satellite transceiver
- 3GPP R17 IoT NTN standard
- DL 200 kHz/UL single + multi-tone
- L-band and S-band: B255/B256/B23/B24
Interfaces
Interfaces
SDIO, USB, I2C, UART, SPI, I2S, PWM, GPIO, BPI/MIPI, SIM, AUXADC
Packaging
Package Type
5.6 mm x 5.6 mm x 1.05 mm TFBGA with 0.5 mm pitch
